Description
| 1. Conductor: | Stranded Bare Copper (7 x 23 AWG) |
| 2. Insulation: | HDPE (CMI-75E)Nominal Wall Thickness: 0.178mm Min. Thickness: 0.153mm |
| 3. Color Code: | Pair 1: Blue & White/Blue Pair 2: Orange & White/Orange Pair 3: Green & White/Green Pair 4: Brown & White/Brown |
| 4. Jacket (BLACK): | 75°C LSZH Compound Nominal Wall Thickness: 0.585mm Min. Thickness: 0.458mm Overall Diameter: 5.8mm ± 0.3mm |
| 5. Electric Requirements: | (Cable length: 300m) Characteristic Impedance (Zo): 85~115Ω (1~250 MHz) DC. Resistance Capacitance Unbalance: 5% Pair-to-Ground Capacitance Unbalance: 330 pF/100m Max. Conductor Resistance: 14.00Ω/100m 20o Max. Mutual Capacitance: 5.6nF/m Max. Spark Test: 2.5kV Nominal Velocity of Propagation (NVP): 69% |
